Connecting to AWS-MQ using C# | .NET Developers

In this fast driven technical world we have new technologies and one of them is AWS-MQ but most of our legacy or web applications will have code written in C#. I will try to explain how you can connect to AWS-MQ using C# code.

Explaining two scenarios -

1. If we have SSO Login to AWS Console.

2. If we have AWS account with IAM login.

1.  C# Code to connect with AWS-MQ when user have SSO Login -

•    Add References Apache.NMS and Apache.NMS.ActiveMQ -



•   Headers used -

            using System;
            using Apache.NMS;
            using Apache.NMS.ActiveMQ.Transport.Tcp;
            using Apache.NMS.ActiveMQ.Transport;
            using Apache.NMS.ActiveMQ;
            using Apache.NMS.ActiveMQ.Util;

•   Create a new function as producer ( ), this will the code which will command AWS-MQ what to create queue and store message.



• Create a new function as consumer ( ), this will the code which will fetch what is stored in AWS-MQ and used to showcase from .NET -



2.  C# Code to connect with AWS-MQ when user have IAM Login -

•   Write the same code, just replace the amq_broker with aws access key Id and secret access key. And try passing it. It will work for you.

Complete Code -

using System;

using Apache.NMS;

using Apache.NMS.ActiveMQ.Transport.Tcp;

using Apache.NMS.ActiveMQ.Transport;

using Apache.NMS.ActiveMQ;

using Apache.NMS.ActiveMQ.Util;

using System.Threading;

namespace WindowsService1

{

    public class CSharp_to_AWSMQ

    {

        public static void producer()

        {

            SslTransportFactory ssl = new SslTransportFactory();

            string amq_broker = "ssl://b-19ffa89d-5b13-48a2-a604-3e8975962250-1.mq.us-east-1" +

                ".amazonaws.com:61617?nms.AsyncSend=true";

            ssl.ServerName = "52.4.134.145"; //IP of server where AMQ is running

            ssl.SslProtocol = "Tls";

            ssl.AcceptInvalidBrokerCert = true;

            Uri uri = new Uri(amq_broker);

            ITransport transport = ssl.CreateTransport(uri);

            //transport.Start();

            Connection connection = new Connection(uri, transport, new IdGenerator())

            {

                UserName = "Soccer",

                Password = "Soccer7654321"

            };

            connection.Start();

            ISession session = connection.CreateSession(AcknowledgementMode.AutoAcknowledge);

            IDestination dest = session.GetQueue("BishalQueue");

            IMessageProducer producer = session.CreateProducer(dest);

            producer.DeliveryMode = MsgDeliveryMode.NonPersistent;

            var text = "Acknowlegement";

            var msg = session.CreateTextMessage(text);

            producer.Send(msg);

            Console.WriteLine("Msg Printed from Producer: " + text);

            connection.Close();

            // connection.Start();  // -> here is error:

        }

        public static void consumer()

        {

            SslTransportFactory ssl = new SslTransportFactory();

            string amq_broker = "ssl://b-19ffa89d-5b13-48a2-a604-3e8975962250-1.mq.us-east-1" +

                ".amazonaws.com:61617?nms.AsyncSend=true";

            ssl.ServerName = "52.4.134.145"; //IP of server where AMQ is running

            ssl.SslProtocol = "Tls";

            ssl.AcceptInvalidBrokerCert = true;

            Uri uri = new Uri(amq_broker);

            ITransport transport = ssl.CreateTransport(uri);

            //transport.Start();

            Connection connection = new Connection(uri, transport, new IdGenerator())

            {

                UserName = "Soccer",

                Password = "Soccer7654321"

            };

            connection.Start();

            ISession session = connection.CreateSession(AcknowledgementMode.AutoAcknowledge);

            IDestination dest = session.GetQueue("BishalQueue");

            IMessageConsumer consumer = session.CreateConsumer(dest);

            IMessage consumerMessage = consumer.Receive();

            ITextMessage consumerTextMesaage = (ITextMessage)consumerMessage;

            Console.WriteLine("Msg Recieved from Consumer: " + consumerTextMesaage.Text);

            connection.Close();

        }

        public static void Main(string[] args)
        {
            Console.WriteLine("Creating Producer Thread");
            Thread prod = new Thread(producer);
            Console.WriteLine("Creating Consumer Thread");
            Thread cons = new Thread(consumer);
            prod.Start();
            cons.Start();
        }

    }

}

For any queries please comment below i will try solving your queries.
